ASTM SA179M Cold Drawn Boiler Steel Tube Minimum Wall Thickness

ZHANGJIAGANG HUA DONG ENERGY TECHNOLOGY CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

ASTM SA179M Cold Drawn Boiler Steel Tube Minimum Wall Thickness

Brand Name : HDT

Place of Origin : Jiangsu , China

MOQ : 5T

Price : 800 - 9000 USD / ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : About 10000 ton / month

Delivery Time : 60-75days

Packaging Details : seaworthy packing for exporting

Product Name : Carbon Steel Seamless Boiler Tube

Application : Tubular Heat Exchanger and Condenser

Third Party Inspection : BV,SGS,ASP

Certificate : ISO9001-2008, API 5L, API 5CT

Contact Now

Seamless cold drawn low carbon steel heat exchanger and condenser tubes ASTM A179/A179M, ASME SA179/SA179M

ASTM A179 covers minimum-wall thickness, seamless cold-drawn low-carbon steel tubes for tubular heat-exchange, condensers, and similar heat transfer apparatus. Tubes shall be made by the seamless process and shall be cold drawn. Heat and product analysis shall be performed wherein steel materials shall conform to required chemical compositions of carbon, manganese, phosphorus, and sulfur. The steel materials shall also undergo hardness test, flattening test, flaring test, flange test, and hydrostatic test.

ASTM SA179M Cold Drawn Boiler Steel Tube Minimum Wall Thickness

Chemistry Composition:

C, %
Mn, %
P, %
S, %
0.06-0.18
0.27-0.63
0.035 max
0.035 max

Mechanical Properties:

Yield Strength (Mpa)
Tensile Strength (Mpa)
Elongation, %
Hardness, HRB
≥180
≥325
35 min
72 max

Application:

A179 seamless steel pipe is widely used in industries such as petroleum, chemical, medical, food, light industry, machinery, instrument, include industrial pipeline and mechanical structure parts, etc.
Standard:ASTM A179
Delivery time : Promptly ( Stock) or 10-40 days (Production) Stock : some are Available MTC: Available

Outside Diameter & Tolerance

Outside Diameter, mm
Tolerance, mm
3.2≤OD<25.4
±0.10
25.4≤OD≤38.1
±0.15
38.1<OD<50.8
±0.20
50.8≤OD<63.5
±0.25
63.5≤OD<76.2
±0.30
76.2
±0.38

Wall thickness & Tolerance

Outside Diamter, mm
Tolerance, %
3.2≤OD<38.1
+20/-0
38.1≤OD≤76.2
+22/-0

Length: 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; and so on.
Max length: 27000mm, also U bending can be offered.

Certification

ASTM SA179M Cold Drawn Boiler Steel Tube Minimum Wall Thickness

ASTM SA179M Cold Drawn Boiler Steel Tube Minimum Wall Thickness
